Dolphin America water level plan sketch with notes

Share

Read as a plan of water levels with handwritten notes, this sketch records how a waterfront drinking house sat in relation to the water around it, a concern for owners and builders who dealt with tides, floods, and cellar drainage. Taverns and saloons were often built near docks, ferry landings, and river edges, where cellars and ground floors were vulnerable to high water. Drawings like this usually served practical purposes, such as planning repairs, settling insurance questions, or deciding where to raise a floor or build a seawall. The notes penciled alongside the lines are worth reading closely, since they often explain what the drafter was trying to solve.
