A careful plan, elevation, and set of cross sections, rendered in ink and watercolor, shows how one lock on the Erie Canal was meant to work. The drawing was made at West Point, where the U.S. Military Academy trained many of the engineers who surveyed and built America's canals and roads in the early 1800s. The Erie Canal, completed in 1825, linked the Hudson River at Albany with Lake Erie at Buffalo, and its locks raised and lowered boats across the state's varied terrain. Drawings like this one show how engineers translated that large public work into exact, buildable detail.
